Mini Quantity: 1 set
Port: Shanghai
Payment Terms: T/T, L/C
Size: depended
Material: Iron & copper
Features: powering
Applications: Generate Electricity
Clients: supplier / manufacturer / company / factory / distributor / agent / final user
Marketing Area: Asia, Africa, Europe, the Arab region
| Generator set Specifications | ||
| Output frequency | 50HZ | |
| Rated speed | 1500rpm | |
| Prime power | 550kva | |
| Standby power | 611kva | |
| Rated voltage | 400v | |
| Phase | 3 | |
| Engine model | YC6TD840L-D20 | |
| Alternator model | WDQ354D | |
| Fuel consumption of 100% load | 7.1Litres/h | |
| Fuel consumption of 75% load | 5.7Litres/h | |
| Voltage regulation rate | ≤±1% | |
| Random voltage variation | ≤±1% | |
| Frequency regulation rate | ≤±5% | |
| Random frequency variation | ≤±0.5% | |
| Engine Specifications | ||
| Engine model | YC6TD840L-D20 | |
| Engine manufacturer | yuchai | |
| Number of cylinders | 4 | |
| Cylinder arrangement | in-line | |
| Cycle | 4 stroke | |
| Aspiration | Naturally | |
| Bore Stroke(mm mm) | 152×180 | |
| Displacement Ratio | 19.598 | |
| Compression Ratio | 14:01 | |
| Speed governor | Electrical | |
| Cooling system | Forced water cooling cycle | |
| Steady speed droop(%) | ≤±1% | |
| Oil Capacity(L) | 52 | |
| Starter motor | DC24V | |
| Alternator | DC24V | |
| Alternator specifications | ||
| Rated frequency | 50HZ | |
| Rated speed | 1500rpm | |
| Alternator Model | WDQ354D | |
| Rated output prime power | 550KVA | |
| Efficiency(%) | 94.3 | |
| Phase | 3 | |
| Rated voltage | 400V | |
| Exciter type | self excitation.brushless | |
| Power factor | 0.8 | |
| Voltage adjust range | ≥5% | |
| Voltage regulation NL-FL | ≤±1% | |
| Insulation grade | H | |
| Protection grade | IP23 | |
